KAPP KX 1 Gear Grinding Machine
max. wheel diameter 250 mm
gear width max. 150 mm
max. module 4,5 / 5
Beooyk2ih0
control 840 D Siemens
number of teeth 1 – 999
Max. swivel +/- 35 °
pitch min. 0,1 mm
pitch max. 1000 mm
axis stroke:
x-axis 220 mm
y-axis 110 mm
z-axis 120 mm
A-Axis 360 °
b – axis -110 / +60 °
C-Axis 360 °
feeds:
max. feed X: 10 m/min
max. feed Y: 10 m/min
max. feed Z: 10 m/min
max. feed A: 2.000 min/-1
max. feed B: 5.400 °/min
max. feed C: 7.000 min/-1
Resolutions:
Resolution XYZ: 0,0001 mm
resolution B: 0,001 °
total power requirement 143 kVA
weight of the machine ca. 11,7 t
dimensions of the machine ca. 6.5 x 3,8 x 2,7 m
Documents
Coolantsystem
CNC-Gear-Grinding-Machine
KAPP – KX 1
– generate- and profilegrinding
– straight- and oblique gearing
