STROJTOS VMC 40 milling machining centers vertical

STROJTOS VMC 40 milling machining centers vertical

x-travel 450 mm
y-travel 400 mm
z-travel 400 mm
control Heidenhain TNC 310
distance spindle nose and table min. 100 mm
table height over floor 810 mm
table surface area 400 x 900 mm
no. of flutes 5 je 14 mm
work piece dimensions max. 450 x 400 x 300 mm
workpiece weight max. 350 kg
turning speeds: 9000 U/min
power requirement 7,5 / 8,2 kW
spindle cone ISO 40 DIN 69871
spindle diameter in front bearing 60 mm
tool numbers 12
diameter of tools max. 80 mm
tool length – max. 200 mm
weight of tools max. 6 kg
tool changing time 4 sec
Qa9ul
feed range x y z 1 – 20 000 mm/min.
rapid motion -longitudinal/cross/vertical 30 m/min
operating pressure 6 bar
weight of the machine ca. 3,46 t
dimensions of the machine ca. 2,14 x 1,58 x 2,61 m

CE signed
Video available on our website.

Electric 400 Volt
Electr. hand wheel HR 410 Heidenhain
Lighting og working area

– INDRAMAT axis drives in X, Y, Z and S
– SCHNEEBERGER roller guide
– Cabin roof fixed
– anchoring material
– machine documentation
You find a video on our homepage.
Machine dealer with own stock of 1600 m²
