NILES ZSTZ 25 Gear Grinding Machine

NILES ZSTZ 25 Gear Grinding Machine

max. wheel diameter:2500 mm
gear width:700 mm
max. module:25
min. module:4
total power requirement:45 kW
weight of the machine ca.:47 t
dimensions of the machine ca.:9.600 x 7.700 x 4.475 mm

Min root diameter 250 mm
Bhhjnvxdoh
Number of teeth range 16-600
Helix angle max. 35 °
Rotary table load max. 30,000 kg
Bed slide travel 710 mm
Axis slide travel (stroke) 760 mm
Rotary table diameter 2000 mm
Table bore diameter 450 mm
Depth of the hole table 2000 mm
Grinding wheel diameter 300-400 mm / 2150 U / min
Grinding wheel width max 127 mm
